status map display as question mark

Menard, Chris Chris.Menard at Aspect.com
Thu Aug 27 15:08:23 CEST 2009


I have this:

# CRM - Prod sun Host
define host{
        name                  prod-sun-server ; The name of this host template
        use                   generic-host    ; generic-host template
        check_period          24x7            ;
        check_command         check-sun-host-alive ; command to check hosts
        check_interval        5               ; check the host every 5 minutes
        retry_interval        1               ; retries at 1 minute intervals
        max_check_attempts    10              ; Check each Linux host 10 times (max)
        notification_period   24x7            ;
        notification_interval 120             ; Resend notifications every 2 hours
        notification_options  d,u,r           ; notifications for specific states
        contact_groups        CRMTeam         ; Notifications
        statusmap_image       sun_server.gd2  ; image on map
        icon_image            sun_server.jpg  ; image on status listings
        register              0
    }

And

define host{
        use                     prod-sun-server       ; Name of host template to use
        host_name               bos1badbp1
        alias                   bos1badbp1
        address                 10.129.33.94
        parents                 bos1clfyapp1,bos1clfyapp2
        2d_coords               297,470               ; location of image on map
        }

The 2d_coords value is a fixed location of host when viewing 'User-Supplied cords' on map

From: K Ramanujan [mailto:KRamanujan at JohnDeere.com]
Sent: Thursday, August 27, 2009 9:00 AM
To: Menard, Chris; nagios-users at lists.sourceforge.net
Subject: RE: status map display as question mark

Yes I have the image in the following location but still I can't see the image can y ou send me the details step where I leave the gap..
/usr/local/nagios/share/images/logos

________________________________
From: Menard, Chris [mailto:Chris.Menard at Aspect.com]
Sent: Thursday, August 27, 2009 6:26 PM
To: K Ramanujan; nagios-users at lists.sourceforge.net
Subject: RE: status map display as question mark

Try adding an image to your host (or applicable templates)

I have, this for my sun box template:

        statusmap_image                 sun_server.gd2

and this for M$ boxes:

        statusmap_image         windows_server.gd2

these images are in:

/usr/local/nagios/share/images/logos
From: K Ramanujan [mailto:KRamanujan at JohnDeere.com]
Sent: Thursday, August 27, 2009 3:11 AM
To: nagios-users at lists.sourceforge.net
Subject: [Nagios-users] status map display as question mark


Hi All,


Could some one let me know how to configure status map. I have configure all the host and service definition also


But when I am click on service status the hosts are display as? mark on all side of the map


[cid:image001.jpg at 01CA26F5.99C72A50]


My windows service definition is

define hostextinfo{

hostgroup_name          windows-servers
        notes           This is the Windows server
         icon_image Logo_Windows.gif
        icon_image_alt  WindowsServer SP2
        vrml_image      Logo_Windows.png
        statusmap_image Logo_Windows.gd2
        2d_coords 100,250
        3d_coords 100.0, 50.0,75.0
        }



Need your help here.

Thanks & Regards,
Ramanujan
